WD10R
The anti-smashing radar WD10R is a new type of vehicle detector, which uses microwave broadband technology and high-speed digital signal processing technology.
It is applicable to vehicle supervision and detection at the entrance and exit of parking lot or underground garage and toll station.
It is an indispensable and important part of intelligent parking system and toll system. Compared with the traditional sense of land, it has the following characteristics and advantages.
Veuillez remplir le formulaire ci-dessous et un de nos représentants vous contactera très prochainement.
INFORMATIONS DE CONTACT
QUI NOUS SOMME !
WDLink Maroc en tant que distributeur au Maroc de Contrôle d’accès ( Barrière Parking, Tourniquets …) et Point de vente dispose d’une large gamme de produits et systèmes permettant de couvrir vos besoins dans ce secteur.
Suivez nous!
Il suffit d’une seconde pour être le premier à découvrir nos dernières nouveautés et promotions …
Features
Adopting 79GHz MMIC technology, the detection accuracy is high and the target is more stable.Environmental adaptability design, equipment can adapt to a variety of use scenarios.Bluetooth mobile phone connection, intuitive setting of various parameters applet, online
debugging of radar, software upgrade.It can identify multiple targets, not only vehicles, but also pedestrians, which can effectively
prevent the brake rod from hitting people.LED light is used to display the working status of radar, which is more intuitive.Automatically adapt to the installation environment, with strong versatility.The recognition range of the radar can be set, and the set configuration parameters can be
automatically memorized.The installation and maintenance of the radar is convenient, and it can be installed quickly by
one person without damaging the ground.It can adapt to various weather conditions and is not affected by electromagnetic interference,
light, dust, rain and snow and other external environment.Specifications
| working voltage: | +9 ~ +24V DC |
|---|---|
| electric current: | ≤ 200mA @ 12Vz |
| Operating frequency range: | 77 ~ 80GHz |
| response time: | < 75ms |
| Support rod length (lane width): | 1 ~ 6m (settable) |
| Anti-smashing area: | Horizontal 0.5-1 m (settable) |
| Detection target: | Vehicles, pedestrians |
| Commissioning mode: | Bluetooth |
| Online update: | Bluetooth |
| Horizontal view: | ±40° |
| Pitching angle of view: | ±15° |
| working temperature: | -40℃ ～ +85℃ |
| Overall dimension: | Ф 107.9mm × 22.8mm |
| Protection grade: | IP66 |
Fiche Technique WD10R
488 KB
29-05-2023
User Manual WD10R
0 MB
29-05-2023
Application WD10R
47,18 MB
05-10-2024
Related products
WD01T
The WD01T is designed to provide unsuper vised access control into .and cut of, high security facililies.
The impenetrable construction virtually eliminates any unauthorized entry to restricted areas. The rigid welded stainless steel construction of the full height rotor turnstiles offers advanced reliability and vandal resistance, and guarantees many years of the turn¬stile trouble-free operation even in unfavourable en-vironments.
The rotor is manufactured in stainless steel and is available in either four section (90 degree) or three section (120 degree) versions
The use of electro-magetic drive and mechanism ensure smooth and quiet operation as well as dy¬namic braking and crossbars positioning.
WD219B
WD219B is a high-quality automatic bollard which is used widely to protect security areas from vehicle intrusion. It is an ideal solution for entrance with high security requirements. Raising time of WD219B is 3 seconds. Even if the intrusion is from high tonnage vehicle in high speed, the bollard will stop the vehicle easily because it is so solid that the vehicle will break after impact instead. There are also some extra safety precautions in the design of WD219B.
The LED bar on the bollard can effectively avoid accidents caused by poor vision of drivers at night. In case of power failure, the bollard can be lowered manually. Equipped with PLC (Programmable Logic Controller), various control methods can be achieved easily, such as biometric readers, remote control and push button station.
The bollard is commonly found in customs, ports, prisons and military bases where traffic guidance is needed to protect people and property. This product provides ideal access control in areas mentioned above and raises the level of security.
WDS1000
Le WDS1000 est une série de tourniquets à barrière pivotante à une voie conçue pour un fonctionnement fluide et silencieux et une faible demande d'énergie. Il est fabriqué en acier inoxydable, ce qui rend le WDS1000 très durable.
Les barrières en verre trempé WDS1000 sont normalement maintenues dans une position verrouillée qui refuse l'accès au côté sécurisé. Une fois que le lecteur du WDS1000 (RFID, empreinte digitale, code QR, code) a reconnu la carte d'accès ou l'empreinte digitale valide de l'utilisateur, ses barrières basculeront automatiquement, permettant ainsi aux utilisateurs de passer du côté sécurisé.
En cas d'urgence, les barrières basculeront automatiquement pour garantir que l'utilisateur puisse accéder rapidement à la SORTIE. En cas de panne de courant, les barrières se déverrouilleront automatiquement afin que l'utilisateur puisse pousser les barrières pour traverser la voie.
